Mark-10
Mark-10 M7-5 Digital Force Gauge
High-speed portable gauge for precision tension and compression testing.
Professional handheld digital force gauge with 5 lbF / 25 N capacity and an industry-leading 14,000 Hz internal sampling rate. Stores up to 5,000 data points with USB, RS-232, Mitutoyo, and analog outputs, and ships with MESUR Lite software.
Specifications
- Capacity
- 5 lbF / 25 N (Series 7 spans 0.5 N – 2.5 kN)
- Accuracy
- ±0.1% of full scale
- Sampling rate
- 14,000 Hz
- Continuous capture
- 5,000 points at up to 14,000 Hz
- Detection modes
- Break detection, 1st / 2nd peak
- Outputs
- USB, RS-232, Mitutoyo, analog
